IGODC9160 Concealed Overhead Door Closer Medium Duty 90º Hold Open 3/4″ with Mounting Clips (Keyed Alike)

Concealed Overhead Door Closer Medium Duty 90º Hold Open 3/4″
✅ Includes mounting brackets for wood or metal frames
✅ Delayed action – holds door open 5-20 seconds
🛍️ Ensure Building Safety Compliance

IGODC9160 Concealed Overhead Door Closer Medium Duty 90º Hold Open 3/4″ with Mounting Clips

• Suitable door weight: Max 120kg.
• Suitable door width: 750~1000mm (29-1/2 inch -39-3/8 inch)
• Durability-500,000 Cycles Tested
• Ambient temperature: -20°C to +50°C
• Compliance With EN 1154
• Compact steel body matches 1-3/4″ x 4″ (44.5 x 101.6 mm) header sections
• Two latching speed for adjustment
• Comes with fitting to mount for glass door/ aluminum doors.
• Can be mounted inside the header or rectangle aluminum tube.
• Can be installed on aluminum and glass doors.

The IGODC9160 Ideal Concealed Overhead Door Closer is a medium-duty, 90° hold-open door closer designed to affix onto the header of conventional doors, up to 120kg in weight. The package includes mounting clips and is easy to install, so you can conveniently secure your door with ease.
