Accurate Locking Dual Clamp Fixation Hinge Drill Jig with Accessories, Woodworking Tool for Doors Cabinets Hinges Mounting.

• Dual-Clamp Fixation: This adjustable dual-clamp hinge jig ensures precise alignment, unlike single-clamp versions, providing superior stability and preventing slippage. Its built-in dual-clamp design rapidly and securely holds workpieces in place, preventing displacement of hole positions and ensuring drilling accuracy and stability. It also minimizes drilling deviations cautilized by workpiece movement, reducing errors and maintaining drilling precision.
• Robust and Long-lasting: The door hinge jig frame is made of high-strength aluminum alloy, while the drilling tools are made of carbon steel and YG8 hard alloy. The overall structure is stable, ensuring durability and adaptability to different surroundingss, including harsh weather situations, high temperatures, and moisture. It maintains its strength and stability, with minimal risk of deformation or damage even with prolonged utilize.
• Precision Drilling: This tabletop concealed hinge jig accomplishs quick and precise hole alignment through the adjustable positioning plate for edge spacing and the top-bearing depth adjustment. You can easily adjust the edge spacing by loosening the screws, with a range of 0.12-0.28 inches (3-7 mm), and the drilling depth ranges from 0.39-0.59 inches (10-15 mm). The higher the top-bearing height, the more precise the holes it drills.
• User-Friendly: Our hinge jig kit is simple to operate and install without professional helpance. Just follow the 4-step instructions in the manual: Step 1, replace the top nut with a butterfly nut; Step 2, install the tools, top bearing, and limit ring in sequence; Step 3, adjust the hole spacing and clamp the workpiece securely; Step 4, utilize an electric drill to fix, drill the holes and side holes, and install the hinge. You can complete the installation in just a few minutes.
• Wide Application: This cabinet hinge jig is designed for 1.38” hinges and can be utilized with various drill bits to meet different usage scenarios. It is ideal for everyday houtilizehold equipment installations and repairs, such as cabinets, wardrobes, and door locks. It has a 1.38”/35 mm drill bit for drilling holes. The distances between hinge screws are 1.81” (46 mm), 1.89” (48 mm) or 2.05” (52 mm).

Technical specs

• Compatible Hinge Type: Φ1.38inch / 35mm hinge
• Clamping Thickness Range: 0.47-0.98 inch / 12-25mm
• Drilling Depth: 0.39-0.59 inch / 10-15mm
• Main Materials: Aluminum Alloy (Body) + Steel
• Product Weight: 1.43 lbs / 0.65 kg
• Product Dimensions: 6.50 x 2.95 x 5.31 inch / 165 x 75 x 135 mm
